Introduction
The APM-CAP2L Cap Printing Machine is a state-of-the-art solution for printing high-quality designs on PP and PE caps with diameters ranging from φ28mm to φ38mm. Designed for industries such as food, beverage, cosmetics, and pharmaceuticals, this high-speed machine achieves up to 1000 caps per minute, ensuring exceptional efficiency for large-scale production. Featuring advanced flame treatment heads for superior ink adhesion, a USA-brand UV curing system for durable finishes, and high-precision magnetic rollers for consistent accuracy, the APM-CAP2L delivers unmatched reliability and performance. With customizable options and easy operation, it's the ideal cap printing machine to elevate your production line.
Key Features of the APM-CAP2L Cap Printing Machine
1. Advanced Surface Treatment
Equipped with flame heads, the APM-CAP2L ensures superior surface treatment, enhancing ink adhesion on PP and PE caps for long-lasting print quality.
2. Customizable Printing Mandrels
Tailor-made printing mandrels guarantee precise positioning, accommodating various cap sizes (φ28mm-φ38mm) for consistent printing results.
3. High-Performance UV Curing System
Utilizes a USA-brand UV system with automatic temperature control and an extraction system to prevent overheating, ensuring maximum lamp efficiency and prolonged equipment lifespan.
4. High-Precision Magnetic Rollers
Features state-of-the-art magnetic rollers to achieve consistent ink application, resulting in vibrant and sharp cap designs.
5. Exceptional Speed and Productivity
Capable of running at speeds of up to 1000 caps per minute, significantly boosting production efficiency while maintaining print accuracy.
Technical Process
1. Manual Feeding Model: Manual handling of tubes for smaller production scales or customized batches.
2. Automatic Feeding Model: Ideal for large-scale production with minimal operator intervention.
Both models follow the same printing process, ensuring consistent quality:
(1) Corona Treatment: Prepares the tube surface for better ink adhesion.
(2) Printing & Varnishing: Applies precise, multi-color prints with a protective varnish coating.
(3) UV Curing: Ensures fast drying for smudge-free, durable prints.
Products Parameter
|
Maximum Running Speed |
1000 pcs/min |
| Printing Colors | 1-2Colors |
| Cap Diameter | 28mm-38mm |
|
Power Requirement |
380V, 3P, 50HZ |
|
Maximum Printing Area |
25mm |
|
Machine Dimension (L*W*H) |
2500*950*1500 mm |
| Applicable Materials | PP, PS, PET |
Maintenance
1. Conveyor System
Regularly inspect and adjust the conveyor belts to ensure smooth cap transportation. Replace worn belts promptly to avoid downtime.
2. Flame Treatment Unit
Clean the flame heads regularly and ensure the gas flow is unobstructed for optimal surface treatment performance.
3. Printing Mandrels
Maintain the mandrels by cleaning them after each production run to prevent ink buildup and ensure alignment precision.
4. UV Curing System
Monitor and clean UV lamps and reflectors periodically to maintain curing efficiency. Replace lamps when nearing the end of their lifespan.
5. Control System
Keep the control panel and touch screen dust-free. Regularly back up software to prevent data loss.
FAQ
Q: What types of caps can this machine print on?
A: The APM-CAP2L is designed to print on PP and PE caps with diameters ranging from φ28mm to φ38mm.
Q: How fast is this cap printing machine?
A: This high-speed cap printing machine can process up to 1000 caps per minute, making it ideal for large-scale production.
Q: Can this cap printing machine handle multi-color printing?
A: Yes, the APM-CAP2L cap printing machine supports 1-8 color offset printing, providing vibrant and precise branding on caps.
Q: Does the cap printing machine require surface treatment?
A: Yes, the APM-CAP2L is equipped with flame treatment heads, ensuring efficient surface preparation for better ink adhesion during the printing process.
Q: What industries is this cap printing machine suitable for?
A: This cap printing machine is widely used in industries such as food and beverage packaging, cosmetics, and pharmaceuticals, where high-quality and efficient cap printing is essential.
Q: How does the cap printing machine's UV curing system work?
A: The machine features a USA-brand UV curing system with automatic temperature control and an extraction system. This ensures consistent curing performance while preventing overheating, resulting in durable prints.
Q: Is this cap printing machine customizable?
A: Yes, the APM-CAP2L cap printing machine is highly customizable. We can tailor components such as printing mandrels, fixtures, and production workflows to meet your specific production needs.
Q: What is included in the cap printing machine's standard package?
A: The standard package includes:
- 1 Automatic Escalator
- 1 Automatic Unscrambler
- 1-8 Colors Offset Printing Unit
- Flame Treatment System
- USA-Brand UV Curing System
- 1 Set of Custom Jig Mandrels
- Unloading System
Q: How do I maintain the cap printing machine for optimal performance?
A: Regular maintenance is essential for ensuring the cap printing machine operates smoothly:
- Clean flame heads and printing mandrels after each use.
- Inspect UV lamps and replace them when necessary.
- Check conveyor belts and other mechanical components for wear and tear.
