Product Introduction
SS106 Glass bottle hot stamping machine is a kind of equipment specially used for hot stamping decoration on the surface of glass bottles. Its working principle is to use high temperature and pressure to transfer metal foil (such as gold foil or silver foil) to the surface of glass bottle through hot stamping mold to form a pattern or text with metallic texture.
Product Features
High Precision
The glass bottle hot stamping machine is equipped with an automatic image positioning system with a positioning accuracy of ±0.05mm. This high-precision positioning effectively reduces the scrap rate. Compared with traditional equipment, the scrap rate is reduced by 30%, which not only saves materials but also greatly improves the consistency of production quality.
Efficient Production
The maximum operating speed of the glass bottle hot stamping machine can reach 1,500 pieces per hour. Based on 8 hours of work per day, it can produce 12,000 products. Compared with the traditional manual hot stamping method (about 300 pieces per hour), the production efficiency is increased by 400%.
Labor Saving
The machine integrates automatic bottle feeding, dust removal, hot stamping, UV curing, and automatic unloading, which can save 50% of labor operation costs. A production line usually requires 4 workers, but after being equipped with this equipment, only 2 people are needed to complete the same production task, which can save the company about RMB 20,000 in labor costs per month.
Product Parameters
|
Max printing diameter |
70mm |
|
Max printing length |
150mm |
|
Max printing speed |
30-50pcs/min |
|
UV power UV /LED |
4000watts/720w |
Product Maintenance
Clean the equipment regularly
After work every day, use a soft cloth to clean the surface of the hot stamping mold to prevent metal foil residue or stains from affecting the hot stamping effect. At the same time, the conveyor belt and positioning device should be thoroughly cleaned regularly to avoid dust and debris accumulation and ensure smooth bottle conveying.
Check and replace wearing parts
During the long-term use of the hot stamping machine, wearing parts such as the mold surface, pressure roller and transmission belt will gradually age or wear. Therefore, it is necessary to check the status of these parts regularly, especially whether there are scratches or wear on the mold surface. If any abnormality is found, it should be replaced immediately.
Lubricate moving parts
Moving parts such as drive shafts and guide rails are key to the operation of the equipment. Regular lubrication can prevent parts from getting stuck or rusting. It is recommended to use suitable lubricants to maintain these parts every week to reduce friction loss and extend the service life of the equipment.
Calibrate pressure and temperature
The pressure and temperature of the hot stamping machine directly affect the hot stamping effect, so the pressure and temperature control system of the equipment need to be calibrated regularly. Especially after replacing the foil or mold, the parameters need to be readjusted to ensure the clarity of the hot stamping pattern.
FAQ
Q: What types of bottles are suitable for glass bottle hot stamping machines?
A: Glass bottle hot stamping machines are suitable for a variety of bottle types, including round, oval and square bottles. The specific applicable bottle sizes are usually 20mm to 100mm in diameter and 50mm to 300mm in height, which can meet the processing needs of different products.
Q: What is the hot stamping speed of the glass bottle hot stamping machine?
A: The hot stamping speed of this equipment can reach 1000 to 1500 pieces per hour, which is an ideal choice for efficient mass production.
Q: How to ensure the glossiness of the hot stamping pattern?
A: The equipment adopts a high-precision hot pressing system, high-quality hot stamping molds and high-reflectivity metal foil materials, combined with intelligent temperature control technology to ensure that the glossiness of the hot stamping pattern is as high as 95GU to enhance the visual effect of the product.
Q: Is the operation of the glass bottle hot stamping machine complicated?
A: The equipment adopts a PLC control system and a touch screen operation interface, and users can complete the operation through simple parameter settings. At the same time, the equipment supports the storage of multiple sets of parameters, which can quickly switch products and reduce the difficulty of operation.
Q: How often does the glass bottle hot stamping machine need equipment maintenance?
A: It is recommended to clean after work every day, lubricate moving parts every week, and check wearing parts such as molds and transmission belts every month.
